350W Coaxial Active Monitor

Wedge monitor stage speakers  provide a perfect sound intelligibility and a high SPL in an extremely light-weight and portable enclosure.

Coaxial design

350W RMS active design

Additional information

Weight15 kg
Brand

Proel

4 in stock

SKU: monitor-wd12a Category: Tag:

Description

System type2-way coaxial vented
Low Frequency Device12” woofer with 2.5″VC
High Frequency Device1” compression driver with 1.35″VC
Angular Coverage80°
Frequency Response50 Hz – 20 kHz
Max SPL at 1mt (peak)124 dB
Amplifier Continuous PowerHF: 50 W CLASS AB

  • LF: 300W CLASS D with SMPS
Input Impedance30 kohm balanced / 15 kohm unbalanced
Input sensitivity0 dBu
ControlsLEVEL, PRESET selector (MONITOR, FOH), GND lift
ConnectorsINPUT: COMBO (XLR-F/JACK) – LINK: XLR-M
Power Supply230 VAC or 120 VAC 50/60 Hz
Maximum Consumption445 W
Rated Consumption*235 W
ConstructionPlywood with black anti-scratch polyurethane paint
Pole adapter1 x side
Handles2 x sides
Monitor Taper36°
Weight15 kg (33 lb)
Dimensions (W x H x D)510x340x500 mm

Additional information

Weight15 kg
Brand

Proel
